ASM-620 - Accessories

Home>Products>Stop modules>Stop modules with damping>ASM-620

Overview accessories ASM-620 – PDF
https://www.asutec.de/wp-content/uploads/2026/02/asm-620-zubehoer-1038x904-1.png

No items found

75000075

Fastening set, TS 2 - for mounting under the section with B = 400 mm
Consisting of cross strut profile 45x90, 4x bracket 45x45 + fastening accessories
Product request Step-file download

75000132

Fastening set, TS 2 - for mounting under the section with B = 480 mm
Consisting of cross strut profile 45x90, 4x bracket 45x45 + fastening accessories
Product request Step-file download

75000133

Fastening set, TS 2 - for mounting under the section with B = 640 mm
Consisting of cross strut profile 45x90, 4x bracket 45x45 + fastening accessories
Product request Step-file download

75000134

Fastening set, TS 2 - for mounting under the section with B = 800 mm
Consisting of cross strut profile 45x90, 4x bracket 45x45 + fastening accessories
Product request Step-file download

75000135

Fastening set, TS 2 - for mounting under the section with B = 1040 mm
Consisting of cross strut profile 45x90, 4x bracket 45x45 + fastening accessories.
Due to the width of the strut profile, it is recommended to use an additional support profile to prevent the cross strut profile from bending when the stopper is lowered.
Product request Step-file download

75000136

Fastening set, TS 2 - for mounting under the section with B = 1200 mm
Consisting of cross strut profile 45x90, 4x bracket 45x45 + fastening accessories.
Due to the width of the strut profile, it is recommended to use an additional support profile to prevent the cross strut profile from bending when the stopper is lowered.
Product request Step-file download

14010008

Push-in L-fitting
G1/8; for tubing outside-Ø 6mm
Product request Step-file download

14010020

Push-in fitting (straight)
G1/8; for tubing outside-Ø 6mm
Product request Step-file download

14010005

Supply air one way flow valve
G1/8, for tubing outside-Ø 6mm
Product request Step-file download

15000004

Size M12x1; (Ø12 x 45 mm); Sn = 4 mm; for flush mounting
Connection: M12x1 connector, 3-pin
Switching output: PNP (NO)
Product request Step-file download

15010001

M12x1 female connector, angled,
LEDs yellow+green, 5-pin, 3-wire,
A-coded, 5 m cable lenght
Product request Step-file download

15030001

M16x1, short version,
for sensors M12x1 with fastening length
36 mm and longer
Product request Step-file download
Previous page Next page

Back to the base product

ASM-620
