In the basic design suitable for use in clean to slightly dirty environments.
In the dust-proof type -SD, the gripper is protected against penetrating substances and can be used in environments with increased degree of contamination.

NC: The gripper has an integrated spring that closes the gripper.
NO: The gripper has an integrated spring that opens the gripper.

Lightweight and sturdy aluminum housing, hard-anodized

Proven T-guides for highest force absorption with integrated lubricant pockets.

Air connection on the side.
Tubeless direct connection at the top possible

Query of the gripper finger position directly with inductive proximity switches or indirectly with magnetic field sensors (C-slot sensors) possible.

No maintenance is required.

Included in delivery is the following accessories:
– mounting screws
– Centering sleeves for gripper fingers
– Screw plugs, for main air connection
– O-rings, for direct air connection
Other accessories are freely selectable according to your environmental conditions.
Asutec offers a wide range of accessories
All supplied accessories are mounted on customer request.
