Slide Stop

Stopping and clearing at junctions

Ideally suited for switching between transverse and longitudinal transport at intersections – controlled individually according to your requirements. Thanks to the particularly slim design of the ASUTEC sliding stops, they can be mounted between two parallel longitudinal sections (distance dimension “a”).

A raised sliding stop has the same function as a corner damper: stopping the workpiece carrier for a change of transport direction.
By lowering the sliding stop, it can be overrun and the workpiece carrier continues the transverse transport.

Available in pneumatic and electric versions.

The Slide Stop is mounted externally to the conveyor profile and between the return unit of the transverse section. The compact design of the Asutec Slide Stop allows mounting between two parallel longitudinal conveyor sections, with a minimum width requirement of “a”.

Function: The key to the function of the Asutec Slide Stop is the ability to position the stop below the transfer level of the workpiece pallet which allows the pallet to pass over the Slide Stop. Based on your control method you determine the default position of the stop, raised or lowered. Working in conjunction with the lift transfer modules and the pallet stops on the longitudinal conveyor sections the Slide Stops allow you to navigate 2-way, 3-way and 4-way intersections as well as bi-directional in-feed / out-feed applications.

In addition to the high level of traffic control, the addition of two ranges of dampening capacity provides reduced impact function over a wide range of payload values.

There are 4 air connections available
for our slide stop ASV-160

  • P1: Lower the stop plate
  • P2: Position the stop plate
  • P3: Retract the stop plate
  • P4: Extend the stop plate
