The largest portfolio.
For every application.
Worldwide.
For every application.
Worldwide.
Proven technology. Maximum compatibility. Long-term investment security.
Choose continuity. Choose ASUTEC.
With ASUTEC, you get full compatibility with your existing installation. With more than 800 feed-through modules, we offer the most comprehensive range on the market – without requiring modifications or adjustments to your machinery.
Patented Self-Locking Mechanism
Our tool changers are the only ones featuring the patented Self Lock mechanism: a maintenance-free, springless locking system without locking pins. This eliminates components that can break, fatigue, or become jammed.
800+ Feed-Through Modules
With more than 800 feed-through modules, ASUTEC offers the most comprehensive range on the market. This allows even complex applications to be configured individually – with full compatibility with your existing installation and without extensive modifications.
Proven in
Real-World Applications
Our tool changers have been used across numerous industries since the 1990s and have proven themselves over decades of industrial operation. This extensive practical experience stands for proven technology, reliable performance, and long-term security.
30+ Years of
Experience
These tool changers have been in industrial use for more than 30 years. A proven technology that no longer needs to prove itself, having demonstrated its reliability under real-world operating conditions for decades.
Patented Self-Locking Mechanism
Our Tool Changers
ASHWQC-1-E-K
Pneumatic tool changer with self-lock mechanism for applications with a payload of 1.4 kg, robot side.
ASHWQC-1-E-A
Matching tool side for ASHWQC-1-E-K
ASWWX-P-3
Pneumatic tool changer with 3 kg handling weight, robot side
ASWWX-T-3
Suitable tool side for ASWWX-P-3
ASWWX-P-10
Pneumatic tool changer with 10 kg handling weight, robot side
ASWWX-T-10
Suitable tool side for ASWWX-P-10
ASHWQC-7-C-SM-E-K
Pneumatic tool changer with self-lock mechanism for applications with a payload of 16 kg, robot side
ASHWQC-7-E-A
Matching tool side for ASHWQC-7-C-SM-E-K
ASHWQC-7-SWS-A
Matching tool side for ASHWQC-7-C-SM-E-K, version with side grooves
ASHWQC-11-E-K
Pneumatic tool changer with self-lock mechanism for applications with a payload of 16 kg, robot side
ASHWQC-11-E-A
Matching tool side for ASHWQC-11-E-K
ASWWX-P-16
Pneumatic tool changer with 16 kg handling weight, robot side
ASWWX-T-16
Suitable tool side for ASWWX-P-16
ASHWQC-20-E-K
Pneumatic tool changer with self-lock mechanism for applications with a payload of 25 kg, robot side
ASHWQC-20-E-A
Matching tool side for ASHWQC-20-E-K
ASHWQC-21-E-K
Pneumatic tool changer with self-lock mechanism for applications with a payload of 25 kg, robot side
ASHWQC-21-E-A
Matching tool side for ASHWQC-21-E-K
ASWWX-P-30
Pneumatic tool changer with 30 kg handling weight, robot side
ASWWX-T-30
Suitable tool side for ASWWX-P-30
ASHWQC-29-EM-SG-E-K
Pneumatic tool changer with self-lock mechanism for applications with a payload of 35 kg, robot side
ASHWQC-29-E-A
Matching tool side for ASHWQC-29-EM-SG-E-K
ASWWX-P-50
Pneumatic tool changer with 50 kg handling weight, robot side
ASWWX-T-50
Suitable tool side for ASWWX-P-50
ASHWQC-46-SG-E-K
Pneumatic tool changer with self-lock mechanism for applications with a payload of 70 kg, robot side
ASHWQC-46-A
Matching tool side for ASHWQC-46-SG-E-K
ASWWX-P-80
Pneumatic tool changer with 80 kg handling weight, robot side
ASWWX-T-80
Suitable tool side for ASWWX-P-80
ASWWX-P-100
Pneumatic tool changer with 100 kg handling weight, robot side
ASWWX-T-100
Suitable tool side for ASWWX-P-100
ASWWX-P-150
Pneumatic tool changer with 150 kg handling weight, robot side
ASWWX-T-150
Suitable tool side for ASWWX-P-150
ASHWQC-160-F-SG-E-K
Pneumatic tool changer with self-lock mechanism for applications with a payload of 300 kg, robot side
ASHWQC-160-E-A
Matching tool side for ASHWQC-160-F-SG-E-K
ASHWQC-210-SM-K
Pneumatic tool changer with self-lock mechanism for applications with a payload of 300 kg, robot side
ASHWQC-210-C-A
Matching tool side for ASHWQC-210-SM-K
Fail-Safe Locking
The locking mechanism keeps the robot-side and tool-side interfaces securely connected even in the event of pneumatic pressure loss.
High Rigidity
The locking mechanism is designed to withstand high torque loads, vibrations, and dynamic movements.
Compact Design
The space-saving design facilitates integration into robot cells where installation space is limited.
Integrated Pneumatic Ports
Depending on the model, pneumatic functions can be routed directly through the tool changer.
Repeatable Coupling
The robot-side and tool-side interfaces are reliably aligned to ensure precise tool engagement with every change.
Expandable Media Transfer
Optional feed-through modules enable the transfer of additional signals, media, or power supplies.
No-Touch Locking
Small gaps or minor misalignments during tool pick-up and drop-off can be compensated for, reducing wear and simplifying robot teaching.
Status Monitoring
Lock and unlock sensors can monitor the locking status and provide feedback to the control system.
Good to Know
Frequently Asked Questions
Are ASUTEC tool changers compatible with my existing Schunk systems?
Yes. ASUTEC tool changers are designed as a compatible replacement solution for Schunk systems. They can replace your existing tool changer without requiring fundamental changes to your system infrastructure. This allows you to continue using your existing robots, interfaces and system concepts.
Do I need to modify my system to switch to ASUTEC?
No. Fundamental modifications to your system are not required. ASUTEC tool changers can replace the existing tool changer while your current infrastructure remains in use – without extensive modifications or conversions.
Can I get tool changers and grippers from a single source?
Yes. ASUTEC offers tool changers, grippers and matching components from a single source. This allows the individual components to be optimally coordinated and used as a complete end-of-arm system.
What applications are ASUTEC tool changers suitable for?
ASUTEC offers tool changers for a wide range of industrial applications – from standard applications to heavy-duty applications. The heavy-duty versions are suitable, for example, for large end effectors, high payloads and demanding material handling, welding and joining processes.
What are the key features of ASUTEC heavy-duty tool changers?
The heavy-duty tool changers are designed for high payloads, high torque loads and dynamic movements. Their robust construction enables precise and repeatable coupling even with heavy tools.
Which media and signals can be transferred through the tool changer?
Depending on the configuration, suitable feed-through modules can transfer compressed air, vacuum, liquids, hydraulics, electrical signals and other media. This allows different supplies and interfaces to be routed directly through the tool changer to the end effector.
Which communication and bus signals are supported?
ASUTEC offers modules for numerous common interfaces and communication standards, including Profinet, EtherNet/IP, DeviceNet, EtherCAT and IO-Link.
Can electrical signals and power also be transferred?
Yes. Suitable modules can be used to transfer sensor, control and switching signals. For applications with higher power requirements, modules are also available for applications such as servo motors or welding current.
What options are available for transferring liquids?
Suitable modules are available for fluid transfer. These can be used to route coolants, other liquids or hydraulic media directly through the tool changer to the end effector.
How is the locking status of the tool changer monitored?
Depending on the configuration, lock, unlock and ready-to-lock signals can be monitored. This enables reliable monitoring of the locking status and integration into the system control.
How are tools and end effectors stored safely?
ASUTEC offers tool stands and docking stations that enable defined and secure placement and pick-up of end effectors. This allows tools to be positioned safely and repeatably within the robot cell.
How flexibly can tool stands be configured?
The docking stations can be adapted to the specific application and available installation space. Different sizes and arrangements allow flexible integration into the robot cell.
How are interfaces and modules protected against contamination?
Depending on the configuration, protective covers can be used. These protect tool-side adapters and connected modules against contamination and help ensure reliable operation.
How extensive is the range of feed-through modules?
ASUTEC offers more than 800 feed-through modules, providing an exceptionally comprehensive range. This makes it possible to implement even complex applications involving different media, signals and interfaces using a standardized tool changer system.
